| PHYSICAL PROPERTIES |
| DENSITY | 8.91 g/cm 3 |
|
MELTING
RANGE | 1300-1350℃ |
|
|
|
|
| CHEMICAL COMPOSITION |
| % | Ni | Cu | Fe | C | Mn | Si | S | Al |
| MIN | 52.00 | BALANCE | | | | | | |
| MAX | 57.00 | 0.50 | 0.15 | 0.10 | 0.1 | 0.024 | 0.05 |
FEATURES Alloy 404 has low magnetic permeability and low Curie temperature.
Because its low magnetic permeability is not significantly affected by processing and fabrication, it is particularly suitable for electronic parts.
APPLICATIONS Specialized electrical and electronic applications.
