UNS NO9925 SEAMLESS PIPE
Huashang
7304419000
The INCOLOY 925 UNS NO9925 Nickel Alloy Seamless Steel Pipe is a versatile material designed for harsh environments combining high salinity, elevated temperatures, and corrosive chemicals. This alloy, a member of the Incoloy family, features a balanced composition of nickel (42-46%), chromium (19-21%), molybdenum (2.5-3.5%), copper (1.5-3.0%), and titanium (0.15-0.60%), creating a unique blend of corrosion resistance, strength, and ductility.
Multi-Environment Resistance: INCOLOY 925 resists pitting, crevice corrosion, and SCC in chloride-rich environments, such as seawater and brine, while also performing well in acidic conditions with low pH. The addition of copper enhances resistance to sulfuric acid and hydrogen sulfide, making it suitable for sour gas applications.
Temperature Versatility: The alloy maintains its mechanical properties from -200°C to 500°C, making it ideal for cryogenic storage and high-temperature processing. It shows excellent oxidation resistance up to 700°C, protecting against scale formation in air or flue gas environments.
Superior Fabrication Qualities: Despite its complex composition, the seamless pipe can be easily welded using standard nickel alloy procedures, with minimal risk of solidification cracking. It also accepts various heat treatments to optimize hardness and ductility for specific applications.
Surface Finish Options: Available with smooth or clad surfaces, the pipe can be customized to reduce friction in fluid flow or enhance wear resistance in abrasive environments, ensuring compatibility with diverse operational requirements.
INCOLOY 925 pipes are widely used in the oil and gas industry, particularly for downhole tubing in high-temperature, high-salinity wells and offshore risers exposed to seawater corrosion. In the marine engineering sector, they serve as condenser tubes and seawater desalination piping, where resistance to biofouling and chloride-induced SCC is critical. The chemical processing industry utilizes these pipes for handling organic acids, such as acetic and formic acid, in polymerization reactors and distillation columns. Additionally, they are employed in the aerospace industry for hydraulic lines and engine components requiring resistance to fuel corrosion and thermal fatigue.
SPECIFICATIONS OFUNS NO6455/DIN W. NR. 2.4610 SEAMLESS PIPE
OD: 1mm-325mm
WALL THICKNESS ：0.2mm-20mm
Length : 12m (Special specifications are available as required)
SPECIFICATIONS | PHYSICAL PROPERTIES | ||||
Seamless pipe and tube | ASTM B 983 | DENSITY | 8.08 g/cm 3 | MELTING | 1311-1366℃ |
CHEMICAL COMPOSITION | |||||||||||||
% | Ni | Fe | Cr | C | Mn | Si | P | S | Mo | Cu | Ti | Al | Nb |
MIN | 42.00 | 22.00 | 19.50 | 2.50 | 1.50 | 1.90 | 0.1 | ||||||
MAX | 46.00 | 22.50 | 0.03 | 1.00 | 0.50 | 0.03 | 0.03 | 3.50 | 3.00 | 2.40 | 0.5 | 0.5 | |
| Product material | Incoloy925，UNS N09925，Alloy925 | ||||||||||
| Supply standards | ASTM B161、B163、B167、B07、B444、B622、B668、B677、B722、B729 .etc | ||||||||||
| Size range | Outer diameter: 6-1219; Wall thickness: 0.889mm~customer requirement; Length: According to customer requirements (applicable to seamless pipes) | ||||||||||
| Product packaging | Wooden crates or according to customer requirements | ||||||||||
