UNS N10276 (DIN W.Nr. 2.4819), also known as Alloy C-276, is a nickel-molybdenum-chromium alloy with exceptional corrosion resistance. Its chemical composition features nickel (Ni) as the base element, chromium (Cr) 14.50%-16.50%, molybdenum (Mo) 15.00%-17.00%, iron (Fe) 4.00%-7.00%, tungsten (W) 3.00%-4.50%, with maximum 2.50% cobalt (Co), 0.01% carbon (C), 1.00% manganese (Mn), and 0.08% silicon (Si).
Adhering to ASTM B622 standards, the seamless pipe offers versatile dimensions: outer diameter (OD) from 1mm to 325mm, wall thickness from 0.2mm to 20mm, and a maximum length of 12m (custom sizes available upon request). Physical properties include a density of 8.87 g/cm³ and a melting range of 1325-1370℃, enabling performance in extreme temperature and chemical environments.
Alloy C-276 resists localized corrosion, stress corrosion cracking, and both oxidizing and reducing media. It withstands ferric and cupric chlorides, hot contaminated organic/inorganic media, formic and acetic acids, seawater, and brine solutions. Notably, it is one of the few materials resistant to wet chlorine gas, hypochlorite, and chlorine dioxide.
Manufactured by a factory with 30 years of seamless pipe expertise, the product benefits from 18 seamless production lines and 3 perforation lines, supporting an annual output of 30,000 tons of austenitic and duplex steel pipes. The facility employs 296 personnel, including 4 senior engineers, 18 engineers, and 38 professional technicians, ensuring technical excellence.
The factory holds ISO9001:2015 certification and is approved by BV, ABS, CCS, DNV/GL, TUV, LR, KR, and other classification societies. It also holds ISO45001:2018 (occupational health and safety) and ISO14001:2015 (environmental management) certifications, as well as CCS factory approval and TUV-PED certification (2014/68/EU).
Alloy C-276 has excellent resistance to localized corrosion, stress corrosion cracking, and to both oxidizing and reducing media, thus making it suitable for a wide variety of chemical process environments, including ferric and cupric chlorides, hot contaminated media (organic and inorganic), formic and acetic acids, seawater and brine solutions. It is one of the few materials that withstands the corrosive effects of wet chlorine gas,hypochlorite and chlorine dioxide.
APPLICATIONS
Chemical processing, waste treatment, pollution control,pulp and paper production, and marine engineering.
The pipe is widely utilized in chemical processing for aggressive media handling, waste treatment and pollution control systems, pulp and paper production, and marine engineering. Its corrosion resistance makes it suitable for harsh industrial environments where reliability and long service life are critical.
Our pipe factory has 296 employees ,including 4 senior engineers,18 engineers and 38 professional technicians.
We can produces 30,000tons of austenitic steel and duplex steel pipes annually with 18 seamless production lines and 3 perforation production lines.
Our pipe factory has been certified to the ISO9001:2015 quality management system and certified by various classification societies (such as BV, ABS,CCS,DNV/GL,TUV,LR,KR etc).
Chemical Composition | |||||||||
% | Ni | Cr | Mo | Fe | W | Co | C | Mn | Si |
MIN | BALANCE | 14.50 | 15.00 | 4.00 | 3.00 | ||||
MAX | 16.50 | 17.00 | 7.00 | 4.50 | 2.50 | 0.01 | 1.00 | 0.08 | |
Specification | Physical Properties | ||||
Seamless pipe and tube | ASTM B 622 | DENSITY | 8.87 g/cm3 | MELTING RANGE | 1325-1370 ℃ |
Specifications Of UNS N10276/DIN W. NR. 2.4819 Seamless Pipe |
OD: 1mm-325mm
WALL THICKNESS: 0.2mm-20mm
Max Length:12m (Special specifications are available as required)
Production Processes |
Quality Control Of Huashang Duplex Steel Seamless Pipe |
1. Raw Materials
Our raw materials come from well-know mills in China, such as Tingshan, Tisco, Bao Steel, Yongxing, Walsn.....
We will do MTC checking (PMI), tensile strength test, surface/dimension inspection for raw material.
2. Production
Specially assigned person shall follow up and check the process flow card and finally keep the copy.
3. Before Shipment
Our quality inspection team responsible for different categories of products. We will conduct routine appearance testing, PMI testing, non-destructive testing. We also equipped with a professional lab that can do physical and chemical properties test. we also can accept the third inspection, such as BV, LR, TUV, ABS, DNV-GL ect.
METALLOGRAPHIC TEST
IMPACT TEST
TENSILE TEST
EDDY CURRENT TESTING
ULTRASONIC TESTING
HARDNESS TEST
TEST BLOCK MEASUREMENT SIZE
MEASURE AFTER PULLING
PULL UP TEST BLOCK
Packaging and Containerization |
Certificate |
Quality management system certificate
Occupational health and safety management system certification
Environmental management system certificate
CCS certificate
TUV-PED certificate
Alloy C-276’s resistance to seawater, brine solutions, and chloride-induced corrosion makes it ideal for marine engineering applications. It withstands the harsh saltwater environment, preventing pitting, crevice corrosion, and stress corrosion cracking.
Yes, with a melting range of 1325-1370℃, Alloy C-276 retains its corrosion resistance and structural integrity at elevated temperatures, making it suitable for high-temperature industrial processes involving aggressive media.
We offer flexible packaging solutions, including wooden cases, paper packaging, plastic packing, and foam packaging. Custom packaging according to customer requirements is also available to ensure safe transportation.
Yes, we welcome third-party inspections from organizations such as BV, LR, TUV, ABS, and DNV-GL. Our quality control process is transparent, and we provide full support for external testing to ensure product compliance.
