| Quantity: | |
|---|---|
1--273mm
Huashang
7507120000
Alloy 718 is an age-hardenable Alloy-chromium alloy that combines corrosion resistance with high strength and good fabricability.
It has high creep-rupture strength at temperatures up to 700℃. Its excellent relaxation resistance contributes to its application in springs.
APPLICATIONS
N10675 is suitable for the applications where N10665 is required. Like N10665,
N10675 should not be used in the presence of ferric or cupric salts as these salts may cause rapid corrosion attack.
Our pipe factory has 296 employees ,including 4 senior engineers,18 engineers and 38 professional technicians.
We can produces 30,000tons of austenitic steel and duplex steel pipes annually with 18 seamless production lines and 3 perforation production lines.
Our pipe factory has been certified to the ISO9001:2015 quality management system and certified by various classification societies (such as BV, ABS,CCS,DNV/GL,TUV,LR,KR etc).
Chemical Composition | |||||||||||||||
% | Ni | Cr | Fe | Mo | Nb+Ta | Co | C | Mn | Si | S | Cu | Al | Ti | P | B |
MIN | 50.00 | 17.00 | BALANCE | 2.80 | 4.75 | 0.20 | 0.65 | ||||||||
MAX | 55.00 | 21.00 | 3.30 | 5.50 | 1.00 | 0.08 | 0.35 | 0.35 | 0.02 | 0.30 | 0.80 | 1.15 | 0.02 | 0.01 | |
Specification | Physical Properties | ||||
Seamless pipe and tube | ASTM B 983 | DENSITY | 8.23g/cm3 | MELTING RANGE | 1260-1335 |
Form | Standard |
|---|---|
Metal Type | UNS N07718 |
Bar | ASTM B637 AMS 5662 AMS 5663 AMS 5664 PWA 1009 PWA 1010 GE B50TF15 |
Wire | AMS 5832 |
Sheet | ASTM B670 AMS 5596 AMS 5597 PWA 1033 GE B50TF14 ASTM B670 ASTM B637 |
Plate | ASTM B670 AMS 5596 AMS 5597 PWA 1033 GE B50TF15 ASTM B670 ASTM B637 |
| Tube | AMS 5589 AMS 5590 |
| Pipe | AMS 5589 AMS 5590 |
Fitting | |
Forging | ASTM B637 AMS 5562 AMS 5663 AMS 5664 PWA 1009 PWA 1010 GE B50TF15 |
Weld Wire | A5.14 ERNiFeCr-2 |
| Weld Electrode | |
Din | 2.4668 |
Specifications Of UNS N07718/DIN W. NR. 2.4668 Seamless Pipe |
OD: 1mm-325mm
WALL THICKNESS: 0.2mm-20mm
Max Length:12m (Special specifications are available as required)
Production Processes |
Quality Control Of Huashang Duplex Steel Seamless Pipe |
1. Raw Materials
Our raw materials come from well-know mills in China, such as Tingshan, Tisco, Bao Steel, Yongxing, Walsn.....
We will do MTC checking (PMI), tensile strength test, surface/dimension inspection for raw material.
2. Production
Specially assigned person shall follow up and check the process flow card and finally keep the copy.
3. Before Shipment
Our quality inspection team responsible for different categories of products. We will conduct routine appearance testing, PMI testing, non-destructive testing. We also equipped with a professional lab that can do physical and chemical properties test. we also can accept the third inspection, such as BV, LR, TUV, ABS, DNV-GL ect.
METALLOGRAPHIC TEST
IMPACT TEST
TENSILE TEST
EDDY CURRENT TESTING
ULTRASONIC TESTING
HARDNESS TEST
TEST BLOCK MEASUREMENT SIZE
MEASURE AFTER PULLING
PULL UP TEST BLOCK
Packaging and Containerization |
Certificate |
Quality management system certificate
Occupational health and safety management system certification
Environmental management system certificate
CCS certificate
TUV-PED certificate
